  Product Category


Classification
Hot Air Seam Sealing Machine
Name
T-1
==Product Features==
  1. Controlled by programmable PLC with high definition display, process can be modified according to
       users' requirements.
  2. Auto controllable temperature with high stability slightly varies between±2℃, Warning device for
       temperature upper limit is installed to protect heating wire.
  3. It has the functions of synchrodrive of the upper and lower wheel chain, auto compensation, and auto reverse.
  4. Double pedal control is designed according to human mechanics, simple and comfortable, suitable
    for long-time operation.
  5. It is possible to work 24 hours continuously with high efficiency.
  6. Blowing-in wind can be filtrated without oil or water by unique heater tube.
  7. Automatic tape loosen system can be added according to specific requirements.
  8. The functions of auto tape clipping, sending and finishing reduce the wastage of raw material.
  9. Super-thin lower column is suitable to sealing product with various sizes.

==Scope==
  Economical Production of Weatherpr-oof Products Such As Rain-Wear,Ski-wear,wet/dry suits, tents,car covers.etc.Seam Sealing Applicable To A large variety of fabrics such as pu,pe,pvc,neoprene,ac,etc,can be used for long,straight and curved seams of all kinds on sheeting and coated materials with A thickness of 0.2mm and more.

==Technical parameter==
Model:
T-1

Power cosumption:

AC~220V 50Hz 2500W Abt

Heater power:

2000W of special heating elements

Heater control

Infinitely variable up to 700oC

Speed:

2~24m/min infinitey variable

Air supply:

0.35~0.5 Mpa

Width of pinch roller:

25mm standard with options for plain points engraved and striped roller

Width of seam sealing tape:

Standard 14mm ~22mm ,other optional

Upper roller lift:

18mm~25mm

Exterior size:

(L)1350mm×(W)600mm×(H)1530mm

Net weight:

140kg

Prevention against jumping over sewing work:

There are adjustable devices to prevent the gun from jumping over the seamed sections when the gun is  moving in ward with the idle wheel starting,or when the gun moving outward with the idle wheel stopping.
